Duplex

Overview

The Fiber Optic Adapter is a high-quality passive component designed to precisely align and connect two fiber optic connectors, ensuring low insertion loss and reliable optical signal transmission. Equipped with a precision alignment sleeve, it securely holds connector ferrules in place for stable performance. Available in multiple connector types, polishing options, and housing configurations, these adapters are widely used in FTTH, FTTx, telecom, data centers, CATV, and enterprise networking applications.

Key Features

• Available in SC, LC, FC, ST, and E2000 connector types
• Supports Single Mode & Multimode, Simplex & Duplex, PC & APC configurations
• Available with plastic or metal body, with or without flange
• Low insertion loss and excellent return loss for reliable optical performance
• Easy push-pull installation with high mechanical durability
• 100% insertion loss (IL), return loss (RL), and visual inspection tested

Technical Specifications

• Connector Types: SC, LC, FC, ST, E2000
• Fiber Mode: Single Mode (SM) / Multimode (MM)
• Configuration: Simplex / Duplex
• Polish Type: PC / UPC / APC
• Sleeve Material: Zirconia Ceramic / Phosphor Bronze
• Body Material: Plastic / Metal
• Dust Cap: Black Plastic
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +85°C
